RR Panels
Our RR Panels are manufactured using high-tensile Prestressed Concrete Steel PC Wire, compliant with IS:6003 standards. These wires, sourced from JSW, are insulated with 25 to 40 mm EPS, ensuring
outstanding durability and resistance to cracking and stress. The panels are pre-cured and ready-to-install, making them ideal for walls and roofs.
DIMENSION OF THE WALL PANEL
- Width 340mm
- Length *2700mm/3000mm
- Thickness 100 & 65mm
GRADE OF STEEL
-
Prestressed Concrete Steel PC
Wire as per IS:6003 4/5mm
dimensional wire
GRADE OF CONCRETE
- M30 & M40
about
Key Features
8 2 8 7
+years
We have been providing
service for 10 years
service for 10 years
-
Excellent Load-bearing Capacity:
Strong enough to withstand significant structural loads. -
Longevity:
Durable and long-lasting. -
Termite Resistant:
Offers protection against termite infestations. - Fireproof: High resistance to fire.
-
Soundproof:
Excellent acoustic insulation. -
Space-efficient:
Thinner walls provide additional carpet area. -
Pre-Cured:
Ready for immediate installation, saving time and resources.
Features
Additional Features
Features
Thermal efficiency
Top-to-bottom rigid insulation can be used within a relatively thin wall, providing a high effective R value. The thermal mass of the concrete provides an added benefit by slowing heat transmission through
the wall, flattening out temperature swings.
- Space Savings: Thinner walls provide additional carpet area up to 10 to 12%.
- Interlocking Technology: Long tongue and groove design for easy installation and uninstallation.
- Integrated Conduits: Electric model conduit boxes and insulation pipes are built into the panels.
Wide Range of Uses
RR Panels are versatile and can be used in:
- Schools
- Malls
- Commercial Buildings
- Restaurants
- Industrial Facilities
- Residential & Multistorey Buildings
- Warehouses
- Cottages
